Product Specifications

additional connections

no

with backflow preventer

no

Built-in fitting model

Finishing section

circulation

no

connection with pay water disp

not possible

Cover plate height

245 mm

Cover plate width

190 mm

with filter

yes

adjustable flow time

yes

functional principle

hydraulic self-closing

for hand shower

no

hygiene flushing

no

diameter nominal

DN 15

inlet size

G 3/4 B

Locking mechanism

Top section, non-ceramic

material casing

stainless steel

material fitting

brass-look

maximum flow time

35 Seconds

minimum flow pressure

1 bar

minimum flow time

5 Seconds

type of mixing

no

with rosettes/cover plate

yes

protective shutdown

no

shower pipe draining

no

sound insulation

no

surface finish casing

satin finished

surface finish fitting

chromed

surface treatment fitting

polished

temperature limit

no

thermal disinfection

no

type of mounting

in-wall installation with box

type of operation

manual operation

type of shower

in-wall fitting

volume flow rate at 3 bar

0.4 l/s

water connection

threaded connection (external)

Accent colour

chrome-look (glossy)

Basic colour

stainless steel-look
