Product Specifications

input supply voltage Hz

50 Hertz (1/second)

filling quantity

1,600

filling quantity uom

ml

lock

key-lock

material

stainless steel

material code

1.4301 Chrome Nickel steel V2A

material thickness

1.2 mm

overall depth

215 mm

overall height

900 mm

overall width

600 mm

protective system IP

IP20

type of mounting

wall mounting

type of operation

sensor operation

type of soap container

integrated refillable tank

Accent colour

white

air velocity

adjustable

blower output

80 Cubic Meter/Hour

input supply voltage Hz

50 Hertz (1/second)

heating power

500 Watt

material

stainless steel

material code

1.4301 Chrome Nickel steel V2A

material thickness

1.2 mm

motor power

500 Watt

overall depth

215 mm

overall height

900 mm

overall width

600 mm

protective system IP

IP20

sound level

76.2 Decibels (A Weighting)

type of mounting

wall mounting

type of operation

sensor operation

Accent colour

white

calculation flow rate cold wat

0.02 l/s

calculation flow rate hot wate

0.02 l/s

diameter nominal

DN 15

inlet size

G 3/8 B

material casing

stainless steel

material code casing

1.4301 Chrome Nickel steel V2A

minimum flow pressure

1 bar

overall depth

215 mm

overall height

900 mm

overall width

600 mm

power supply connection

230 V AC

power consumption

1,100 Voltampere

Type of power supply

Mains power supply

protective system IP

IP20

Spout

fixed

type of mounting

wall mounting

type of operation

sensor operation

type of sensor

opto-electronic sensor

volume flow rate at 3 bar

0.02 l/s

Accent colour

white

calculation flow rate cold wat

0.02 l/s

calculation flow rate hot wate

0.02 l/s

minimum flow pressure

1 bar

overall depth

215 mm

overall height

900 mm

overall width

600 mm

power supply connection

230 V AC

power consumption

1,100 Voltampere

protective system IP

IP20

volume flow rate at 3 bar

0.02 l/s
