Product Specifications

additional connections

false

with backflow preventer

true

calculation flow rate cold wat

0.15 l/s

calculation flow rate hot wate

0.15 l/s

circulation

false

connection with pay water disp

not possible

with filter

true

adjustable flow time

true

functional principle

hydraulic self-closing

for hand shower

true

hygiene flushing

false

diameter nominal

DN 15

inlet size

G 1/2 B

Locking mechanism

Top section, non-ceramic

material fitting

brass-look

maximum flow time

35 Seconds

minimum flow pressure

1 bar

minimum flow time

5 Seconds

type of mixing

true

with rosettes/cover plate

true

protective shutdown

false

shower pipe draining

false

sound insulation

false

surface finish fitting

chromed

surface treatment fitting

polished

temperature limit

true

thermal disinfection

false

type of mounting

wall mounting

type of operation

manual operation

type of shower

wall fitting

volume flow rate at 3 bar

0.25 l/s

water connection

S-connections

position of water connection

from backside

Accent colour

none

Basic colour

chrome-look (glossy)
