Product Specifications

additional connections

no

with backflow preventer

no

calculation flow rate cold wat

0.15 l/s

circulation

no

connection with pay water disp

not possible

with filter

no

adjustable flow time

yes

functional principle

hydraulic self-closing

for hand shower

no

hygiene flushing

no

diameter nominal

DN 15

inlet size

G 3/4 B

Locking mechanism

Top section, non-ceramic

material fitting

brass-look

maximum flow time

35 Seconds

minimum flow pressure

1 bar

minimum flow time

5 Seconds

type of mixing

no

with rosettes/cover plate

no

protective shutdown

no

shower pipe draining

no

sound insulation

no

surface finish fitting

chromed

surface treatment fitting

polished

temperature limit

no

thermal disinfection

no

type of mounting

pipe mounting

type of operation

manual operation

type of shower

wall fitting

volume flow rate at 3 bar

0.2 l/s

water connection

threaded connection (external)

position of water connection

from bottom

Accent colour

none

Basic colour

chrome-look (glossy)
