KWC F5S-Mix

Self-closing wall-mounted mixer

F5SM1010

2030040317 - F5SM1010 - F5S - F5S-Mix self-closing wall-mounted mixer

KWC F5S-Mix

Self-closing wall-mounted mixer

F5SM1010 2030040317 EAN/GTIN: 7612982245770

F5S mix self-closing wall-mounted mixer DN 15 as single-mixer tap for wall mounting with lockable swivelling spout, for sanitary facilities. FRAMIC self-closing mixing cartridge, hydraulically controlled, low-maintenance and stagnation-free, with ceramic disc technology, self-closing, flow pressure-independent due to medium-separated design. Stepless adjustment of flow duration. With adjustable, turn-proof temperature stop. Connects to hot and cold water. All-metal construction, high-polished chromium-plated brass. Aerator with an integrated flow regulator 3.0 l/min. With adjustable and lockable connections with backflow preventer and strainers, completely covered with depth-adjustable screw rosettes. Projection 255 mm.

Product Specifications

with backflow preventer
true
calculation flow rate cold wat
0.07 l/s
calculation flow rate hot wate
0.07 l/s
compatible A3000 open
false
depressurised
false
with filter
true
adjustable flow time
true
functional principle
hydraulic self-closing
hygiene flushing
false
diameter nominal
DN 15
inlet size
G 1/2 B
Locking mechanism
Top section, ceramic
material fitting
brass-look
maximum flow time
35 Seconds
minimum flow pressure
0.5 bar
minimum flow time
5 Seconds
type of mixing
true
Pop-up waste set
false
with rosettes/cover plate
true
protective shutdown
false
sound insulation
false
Spout
rotating, bottom
spout projection
255 mm
surface finish fitting
chromed
surface treatment fitting
polished
temperature limit
true
thermal disinfection
false
type of mounting
wall mounting
type of operation
manual operation
type of tap
bib tap
volume flow rate at 3 bar
0.05 l/s
water connection
S-connections
Accent colour
none
Basic colour
chrome-look (glossy)
