Product Specifications

additional connections

false

with backflow preventer

true

circulation

false

compatible A3000 open

false

connection with pay water disp

not possible

with filter

true

adjustable flow time

true

functional principle

hydraulic self-closing

for hand shower

false

hygiene flushing

false

diameter nominal

DN 15

inlet size

G 1/2 A

Locking mechanism

Top section, ceramic

material casing

stainless steel

material code casing

1.4301 Chrome Nickel steel V2A

material fitting

brass-look

maximum flow time

35 Seconds

minimum flow pressure

1.5 bar

minimum flow time

5 Seconds

type of mixing

true

overall depth

90 mm

overall height

1,160 mm

overall width

235 mm

with rosettes/cover plate

true

protective shutdown

false

shower pipe draining

false

Shower head

separately

with shower set

false

sound insulation

false

surface finish casing

satin finished

surface finish fitting

chromed

surface treatment fitting

polished

temperature limit

true

thermal disinfection

false

type of mounting

wall mounting

type of operation

manual operation

type of shower

shower panel

volume flow rate at 3 bar

0.15 l/s

water connection

hose (gland nut)

position of water connection

from top / backside

with soap dish

false

Accent colour

chrome-look (glossy)

Basic colour

stainless steel-look
